Power Lifepo4 Wall Batteries 48V 100Ah 400Ah 200 Amp 15Kw 300Ah 51.2V Li Lithium Ion Battery
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Overview
Quick Details
| Place of Origin: | Guangdong, China | Brand Name: | LINKAGE |
| Model Number: | LKG-48-200-S-3 | Battery Type: | LiFePO4, LiFePO4 |
| Dimensions: | 710*450*192 | Shell material: | Iron shell |
| Specification: | 51.2V 200Ah | Energy: | 5.12KWh |
| Cycles: | >6000 times(80%DOD) | Installation Method: | Foldable Type |
| Enclosure Protection Level: | IP65 | Features: | Long Service Life/Easy Operation / Low noise |
| Application: | Garden Tools, UPS Systems,Industrial and Medical Equipment etc |
Supply Ability
| Supply Ability | 2000 Piece/Pieces per Month |
Packaging & Delivery
| Picture Example: |
Video Description
Product Detail
Product Paramenters
Product Model | LKG-48-200-S |
Rated Voltage | 51.2V |
Rated Capacity | 200Ah |
Total Power | 5.12KWh |
Color | White |
Months Self Discharge | <3% |
Dimensions | Customized |
Internal Resistance | ≤35mΩ |
Cycle Life | >6000 times(80%DOD) |
Warranty | 18Months |
Installation Method | Foldable Type |
OEM/ODM | Accepatable |
Applications | Solar Panels,Wind Power System,UPS, Backup Power,Outdoor Microstation,Home Energy Storage, Industrial Energy Storage,Emergency Light,RV...... |
Mechanical Data | |
Cell&Capacity | Lifepo4 cell 3.2V100AH |
Shell material | Iron shell |
Working Condition | |
Operating Temperature | Charging 0 ~ 45℃ Discharging -20 ~ 60℃ |
Storage Temperature | 0℃ to 40℃ |
Enclosure Protection Level | IP65 |
Charge Data | |
DC Normal Charge Voltage | 58.4±1Vdc |
Charge Mode | 0.2C to 58.4V, then 58.4V, charge current to 0.02C (CC/CV) |
Recommended Charger Current | ≤25A |
Allowed Max. Charge Current | 100A |
Cut-off Voltage | 58.4±1Vdc |
Discharge Data | |
Continuous Discharge Current | 200A |
Allowed Max. discharge current | 300A（30S） |
Discharge cut-off voltage | 40V |
