48Volts 50Ah Lifepo4 12V 20Ah Golf Trolley Batteries Lithium Ion Battery Pack For Electric Golf Carts
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Overview
Quick Details
| Place of Origin: | Guangdong, China | Brand Name: | LINKAGE |
| Model Number: | LKG-48V-50Ah-3 | Battery Type: | LiFePO4, LiFePO4 |
| Battery Specifications: | 15S5P/48V/50Ah | Battery Shell: | Sheet Metal Shell |
| Battery Size: | 420*300*170mm (Max) | Cycles: | 3000 times |
| Communication Management: | CAN | Charging Voltage: | 54.75V |
| Warranty: | 18 months | Weight: | 30Kg |
| Application: | Tourist Car,Golf Cart,Forklift Airport Shuttle etc. |
Supply Ability
| Supply Ability | 2000 Piece/Pieces per Month |
Packaging & Delivery
| Picture Example: |
Product Detail
Product Paramenters
Battery Specifications | 15S5P/48V/50Ah |
Cell Model | 0150651500/3.2V/10Ah |
Nominal Voltage | 48V |
Nominal Capacity | 50Ah |
Charging Voltage | 54.75V |
Battery Shell | Sheet Metal Shell |
Battery Weight | 30Kg |
Product Size | 420*300*170mm (Max) |
Charging Current | ≤15A |
Discharge Current | 100A |
Instant Discharge Current | 150A |
Discharge Cut-off Voltage | 30V |
Internal Resistance Of Finished Product | ≤100mΩ |
Lithium Battery Protection | Short Circuit Protection, Overcharge Protection, Overdischarge Protection, Overcurrent Protection, Temperature Protection,Balance, etc. |
Charging Temperature | 0～45℃ |
Discharge Temperature | -20～60℃ |
Storage Temperature | -20～35℃ |
Temperature Protection | 70℃±5℃ |
Communication Management | CAN |
OEM/ODM | Accepatable |
Application | Tourist Car,Golf Cart,Forklift,AGV Car, Airport Shuttle,Sonic Patrol Vehicle etc. |
